Material:

Contact: Phosphor Bronze
Contact Plating: 0.000150" Tin over 0.000100" NNickel Underplating
Insulator: PBT; rated UL94V-O

Electrical:

Current Rating: 1 Amp Max.
Contact Resistance: 30 Milliohms. Max.
Insulation Resistance: 1000 Megohms Min. DC 500V
Dielectric Strength: 500V AC
Operation Temperature: -25^oC to +85^oC
